Nome / Name | Breda Ba. 88 "Lince" |
Carattestistiche/ Type | Bombardiere veloce /Assaltatore monoplano bimotore |
Anno di Costruzione Year of constr. | 1936 |
Primo Volo/ First flight | ottobre 1936 pilota Furio Niclot |
Progettista/ Eng. | Ing. Antonio Parano Ing. Giuseppe Panzeri |
Equipaggio n. /Crew | 2 |
Ap. Alare / mt. Span wings | 15,60 |
Lunghezza/ mt. Lenght | 10,79 |
Altezza/ mt. Height | 3,10 |
Sup. Alare mq / Wing area | 33,34 |
Motore -i / Power Plant-s | 2 Piaggio P.XI RC40 da 1000cv ciascuno a mt 4000 |
Peso max / Max weight | 6750 kg. |
Peso a secco / Empty weight | 4650 kg. |
Carico utile / Loaded weights | 1000 kg. di bombe |
Armamento / Armament | 3 mitr. da 12,7 mm + 1 mitr. da 7,7mm |
Vel. max/ Max speed | 490km/h |
Tangenza prat. / | 8000 mt ( max) |
Autonomia / Range | 1640 km |
Produzione / Production | 148 esemplari |
Varianti / Special Type | Breda 88M :Alcuni esemplari maggiorati di alla di 2 mt. installazione freni in picchiata e motori Fiat A74 |
